SUPERMICRO MBD-X10DAX-O Extended ATX Server Motherboard

Features

  • Supports Hyper-Speed
  • Supports 3-way Geforce SLI (4-way SLI support for dual GPU graphics cards)
  • Dual socket R3 (LGA 2011) supports Intel® Xeon® processor E5-2600 v4†/ v3 family; QPI up to 9.6GT/s
  • Intel® C612 chipset
  • Up to 2TB† ECC 3DS LRDIMM , up to DDR4- 2400†MHz ; 16x DIMM slots
  • 3 PCI-E 3.0 x16, 2 PCI-E 3.0 x8, and 1 PCI-E 2.0 x4 (in x8) slot
  • Dual GbE LAN ports via Intel® i210
  • 10x SATA3 (6Gbps) ports w/ Intel C612 controller; RAID 0, 1, 5, 10
  • 6x USB 3.0 (4 rear, 2 via header) 5x USB 2.0 (2 rear, 2 via header, 1 Type A)
  • 7.1 HD Audio with optical S/PDIF
  • Thunderbolt Add-on-Card support

Specifications

Product SKUs
MBD-X10DAX -BX10DAX (Bulk Pack)
Physical Stats
Form FactorE-ATX
Dimensions12' x 13' (30.5cm x 33.0cm)
Processor/Cache
CPU
  • Intel® Xeon® processor E5-2600 v4†/ v3 family (up to 160W TDP **)
  • Dual Socket R3 (LGA 2011)
Cores / CacheUp to 22 Cores† / Up to 55MB† Cache
System BusQPI up to 9.6 GT/s
Note† BIOS version 2.0 or above is required
Note** Motherboard supports this maximum TDP. Please verify your system can thermally support.
System Memory
Memory Capacity
  • 16x 288-pin DDR4 DIMM slots
  • Up to 2TB† ECC 3DS LRDIMM, 1TB ECC RDIMM
Memory Type2400†/2133/1866/1600MHz ECC DDR4 SDRAM 72-bit
DIMM Sizes
  • RDIMM: 64GB, 32GB, 16GB, 8GB, 4GB
  • LRDIMM: 64GB, 32GB
  • 3DS LRDIMM: 128GB
Memory Voltage1.2 V
Error DetectionCorrects single-bit errors
On-Board Devices
ChipsetIntel® C612 chipset
AHCI SATASATA3 (6Gbps); RAID 0, 1, 5, 10
SCU SATASATA3 (6Gbps); RAID 0, 1, 5, 10
Network Controllers
  • Dual Gigabit Ethernet LAN ports via Intel® i210
  • Virtual Machine Device Queues reduce I/O overhead
  • Supports 10Base-T, 100BASE-TX, and 1000BASE-T, RJ45 output
AudioRealTek ALC888 7.1 High Definition Audio with S/PDIF header
Input / Output
SATA10x SATA3 (6Gbps) ports
LAN2x RJ45 Gigabit Ethernet LAN ports
USB
  • 6x USB 3.0 ports (4 rear + 2 via header)
  • 5x USB 2.0 ports (2 rear + 2 via header + 1 Type A)
Audio7.1 HD Audio with optical S/PDIF
DOMDOM (Disk on Module) power connector
TPM1x TPM 1.2 20-pin Header
Expansion Slots
PCI-Express
  • 3 PCI-E 3.0 x16
  • 2 PCI-E 3.0 x8
  • 1 PCI-E 2.0 x4 (in x8)
System BIOS
BIOS Type128Mb SPI Flash EEPROM with AMI BIOS
BIOS Features
  • Plug and Play (PnP)
  • PCI 2.3
  • ACPI 1.0 / 2.0 / 3.0 / 4.0
  • USB Keyboard support
  • SMBIOS 2.7.1
  • UEFI 2.3.1
Management
Software
  • NMI
  • SuperDoctor® 5
  • Watch Dog
Power Configurations
  • ACPI / APM Power Management
  • Power-on mode for AC power recovery
PC Health Monitoring
Voltage
  • Monitors for CPU Cores, +1.8V, +3.3V, +5V, +12V, +3.3V Standby, +5V Standby, VBAT, Memory Voltages.
  • 6 Phase-switching voltage regulator
FAN
  • 8x 4-pin fan headers (up to 8 fans)
  • 8x fans with tachometer monitoring
  • Status monitor for speed control
  • Pulse Width Modulated (PWM) fan connectors
Temperature
  • Monitoring for CPU and chassis environment
  • CPU thermal trip support
  • Thermal Control for 8x Fan Connectors
  • Thermal Monitor 2 (TM2) support
  • PECI
LED
  • CPU / System Overheat LED
  • Suspend static indicator LED
  • UID/Remote UID
Other Features
  • Chassis Intrusion Detection
  • Chassis Intrusion Header
  • SDDC Support
  • RoHS

What's in the Box

Driver

Learn more about the Supermicro MBD-X10DAX-O

Model

Brand
SUPERMICRO
Model
MBD-X10DAX-O

Supported CPU

CPU Socket Type
Dual LGA 2011-3
CPU Type
Intel Xeon processor E5-2600 v3 family (up to 160W TDP )

Chipsets

North Bridge
Intel C612

Memory

Number of DDR4 Slots
16 x 288-pin
DDR4 Standard
DDR4 2133 / 1866 / 1600
Maximum Memory Supported
1TB
ECC Supported
Yes

Expansion Slots

PCI Express 3.0 x16
3
Other Slots
3 PCI-E 3.0 x16
2 PCI-E 3.0 x8
1 PCI-E 2.0 x4 (in x8)

Storage Devices

SATA
10 x SATA 6.0Gb/s
SATA RAID
0/1/5/10

Onboard Audio

Audio Chipset
Realtek ALC888

Onboard LAN

LAN Chipset
Intel I210

Rear Panel Ports

RJ45
2 x RJ45 Gigabit Ethernet LAN ports
USB 1.1/2.0
2 x USB 2.0
USB 3.0
4 x USB 3.0
Audio Ports
7.1 HD Audio with optical S / PDIF

Features

Features
Dual socket R3 (LGA 2011) support Intel Xeon processor E5-2600 v3 family; QPI up to 9.6GT/s
Intel C612 chipset
Up to 1TB ECC DDR4 2133 MHz; 16x DIMM slots
3 PCI-E 3.0 x16, 2 PCI-E 3.0 x8, and 1 PCI-E 2.0 x4 (in x8) slot
Intel i210 Dual port GbE LAN
10 x SATA3 (6 Gbps) ports w/ Intel C612 controller; RAID 0, 1, 5, 10
6 x USB 3.0 (4 rear, 2 via header), 5 x USB 2.0 (2 rear, 2 via header, 1 Type A)
7.1 HD Audio with optical S/PDIF

Dimensions

Form Factor
Extended ATX
Dimensions (W x L)
12.0' x 13.0'
  • Warranty
  • Limited Warranty period (parts): 1 year
  • Limited Warranty period (labor): 3 years
  • Manufacturer Contact Info
  • Manufacturer Product Page|
  • Website: https://www.supermicro.com/index_home.cfm|
  • Support Phone: 1-408-503-8000
  • Support Website|
  • Return Policies
    • Return for refund within: Non-refundable
    • Return for replacement within: 30 days
  • This item is covered by Newegg.com's Replacement Only Return Policy.
Ownership: 1 month to 1 year

Pros: Has everything you could possibly need.

Cons: None that I can think of.

Ownership: 1 month to 1 year
UPDATE YOUR BIOS ***FIRST***! :DWIth 2TB of memory and the ability to upgrade my processors to whatever insane setup I want down the road.... 44 cores? 88 threads? Sure. Right now I'm happy with 20 cores and 40 threads.
I've paired this with 4 x 32gb Black Diamond 2400 ECC DDR4. I should've bought 4 sticks as the price has gone up almost 100% thanks to increased demand. I'll wait until prices drop again.

Cons: So there's a few things to mention here.
1: Update your bios because if you do not you WILL have USB connectivity and boot issues. Since updating all my issues have calmed down.
2: This board is listed as E-ATX. It sort of is... I got a Lian Li PC-1000LB (model #?) which is an e-atx case but it was missing something like 4 or 5 holes so I drilled those holes and made it work. Fitment in this case works but it is VERY tight especially when you watercool using the top and front radiators.
3: Would've liked an additional USB 3.0 front header. I realize there's dead space on the motherboard used by other components on different X10 boards but surely it would've been possible somewhere as this is a workstation board.

Other Thoughts: Be aware of tight fitment on this board in cases. The memory slots on the top sit very close to my radiator making putting a fan on it impossible. I plan on ducting two fans into the radiator from the case door. I would also suggest buying 8 sticks of memory to utilize quad channel DDR4 unlike my silly mistake of only buying four.
The PCI slot options in the BIOS are daunting and have no explanation as far as what they do so that's something else to be aware of. Not touching them is probably a good idea. Supermicro gave me no explanation as to what all they options do when asked.
Lastly, I have a Intel X540-T2 card which seems to sporadically work. I have another on order which hopefully will work but there might be a compatability issue there. You *WILL* have to disable onboard LAN if you want your system to boot WITH a 10Gb Intel card.
UPDATE: The X540-T2 card I got was defective. I have since replaced it and it works just fine.

Thank you for your comment! Supermicro needs your comment to improve our quality and service. If you still have any question, feel free to contact us. Please see the below technical support contact information:
Phone: (408)503-8000
Hours: 9:00 a.m – 6:00 p.m. Pacific Time (Monday – Friday)
Email address: support@supermicro.com
You can also submit your issue online: https://webpr3.supermicro.com/Support/login.aspx?
Please do not hesitate to contact us if you have any question.
Thank you!
SM Technical Support
External Link(s):
Submit your issue|
Verified Owner

Pros: After MUCH research on Newegg, I have had no issues whatsoever and so glad I went with this motherboard after years using Gigabyte 2oz boards. No BIOS or USB issues whatsoever. Dropped in dual E5-2620s, 8x16Gb Kingston 2400 ECC, two Noctua NH-L12s using only supplied 120mm Fans, Fanless 750Ti and Corsair RM850I into a Silverstone GD08B. Knew I had to drill/tap two holes into the HTPC case, use Windows Pro x64 and set RAM to 2400 in BIOS. Booted up first try. Got what I wanted, complete silence running 32 Threads at 100% for 3 straight hours !!!

X10dax

Cons: None

Ownership: more than 1 year
Bad BIOS Handles Built-In USB Badly

Cons: I've started with BIOS 1.0a. Six months later, after burning 2.0a, we have some slight improvement in usb functionality-- but nowhere near right. The problem appears to be the complexity and responsibility of a UEFI BIOS to actually enumerate USB 3.0 devices, and emulate USB 2.0 as well, and the inability of AMI to meet the specs. Since there are so few BIOS makers, Supermicro really has no options to fix this, unless AMI decide to get it right. In practice, this means:
1. Abandon the idea that devices plugged into different motherboard ports don't interact with each other, and with the boot process.
2. Scratch your head, swap plugs, hubs, and devices ad-infinitum, and give up.
3. Install an Inatek or other vendor 7 port USB card. Anything based on the Fresco Logic chipset does everything that Intel/AMI cannot. Except: boot into BIOS, which brings us to the next point.
4. You might expect that every usb keyboard will get you into the BIOS. Not! Happy Hacker keyboards don't. Discover which of your keyboards works for this.
Are we done yet? No!
5. You won't be able to boot into the BIOS if any other device is plugged into any other motherboard USB port. You'll get the famous 5-beep code, and the machine will continue into OS boot all the while you're pounding away at 'DEL'.
Confusing? Yeah! Excusable? Noooo Wayyyy!!!

Other Thoughts: The whole ball of wax is just a continuation of a nasty industry habit: writing specs that can't be fulfilled in practice until long after the product is obsolete, if ever. Once you learn to expect things to be partly broken you'll be 'very happy' with this board.

Thank you for your comment! Supermicro needs your comment to improve our quality and service. If you still have any question, feel free to contact us. Please see the below technical support contact information:
Phone: (408)503-8000
Hours: 9:00 a.m – 6:00 p.m. Pacific Time (Monday – Friday)
Email address: support@supermicro.com
You can also submit your issue online: https://webpr3.supermicro.com/Support/login.aspx?
Please do not hesitate to contact us if you have any question.
Thank you!
SM Technical Support
External Link(s):
Submit your issue|
Ownership: 1 week to 1 month

Pros: One of the only 2-CPU boards supporting SLI. I only have it running one CPU for now, but it's rock solid.
Customer service seems responsive and helpful.
Lots of fan headers.
The RAM slots are far enough away from the top PCIe slot that a half-length PCIe card can fit with no problem.

Cons: Now the problems with actually getting SLI up and running:
Unlike SLI-certified boards, this one does not come with an SLI bridge, so you'll have to buy one separately. Even then, though, I couldn't get the video card driver to see that the two cards were capable of SLI. It looks like BIOS 2.0 doesn't actually support SLI. I e-mailed Supermicro, who responded (in 12 minutes!) with a beta BIOS and instructions on how to flash it. The beta BIOS then worked perfectly.
Other minor issues:
- The manual lists level 1-4 for 'Supermicro Hyper-Speed', but only 1 and 2 were available for me. (just for info: the level is the percentage BCLK overclock, so level 2 runs the BCLK at 102MHz instead of 100MHz)
- With only one CPU, the only way to use SLI is with the video cards right next to each other, which raises the temperature of the top one dramatically.
- Although there were a lot of fan headers, the actual fan speed control is lacking. (Setting it to 'optimal' seems to work OK, but I wish there were more options)
- Stickers on the power connectors say 'both 8pin required for heavy load configuration,' implying that you don't always need both, but the manual says you must use both or your warranty is void.
- The I/O shield has PS/2 and 9-pin serial cutouts, but the board does not have those connectors.

Other Thoughts: This board seems rather expensive for what is essentially a bunch of wires between a few connectors. The only real chip on it is the C612 chipset. I'm used to 'enthusiast' boards with extra USB ports, M.2 slots, WiFi, and other add-ons for this price.
I definitely would have liked some M.2 slots for this. 8 PCIe lanes from CPU1 go unused - they are reserved for the RAID controller on the X10DAC version of this board.
All in all, there were no major surprises. Despite the downsides, I'd still get this board again. Took off 1 star due to SLI issues and price/value.

Ownership: 1 week to 1 month

Pros: I started out with the Asus Z10PE-D8WS, but it wouldn't post,
and as I had a past experience with a sabertooth board I changed to Supermicro MDB-X10DAI, just to find out I would really like this one, supporting SLI and Hyper speed. Unfortunately the Newegg website didn't list this one under the Dual 2011-3 options, nor the Asus board actually. The best option is to look for the C612 Chipset.
Both SuperMicro boards posted right away and in spite
of my limited amount of server board builds all their default set ups made it really easy to put it all together.
You need to down load the driver disc, but it all worked flawless.

Cons: None

Supermicro X10dax Usb Controller Driver Download

Through the Newegg EggXpert Review Program, Newegg invites its best reviewers, known as EggXperts, to post opinions about new and pre-release products to help their fellow customers make informed buying decisions.Click here for more details.

Usb Controller Driver Free Download

Loading...
Supermicro's new X10DAi workstation motherboard can run three video cards, tops out at 1TB of DDR4 RAM, and uses the latest Intel Haswell-EP processors.
By:William Harmon | Motherboards in IT/Datacenter | Posted: Oct 14, 2014 2:05 pm
Page 1 [Introduction]

Introduction

The Supermicro X10DAi workstation motherboard is one of three products in this class. These are X10DAi, X10DAC, and X10DAX.

The basic motherboard is the X10DAi, which we will review here. The X10DAC adds an LSI 3008 SAS3 (12Gbps controller) and enhanced network ports. The X10DAX adds overclocking features (BCLK only).

All three motherboards support dual Intel E5-2600 v3 (Socket R3) Haswell-EP processors based on Intel's 22nm processing Technology. Supermicro designed these motherboards as balanced solutions that deliver performance, power efficiency, and feature load.

Using the PCH C612, the X10DAi motherboard supports Intel's Node Manager 3.0, Intel Management Engine, and new DDR4 with speeds up to 2133MHz. The end result is the X10DAi is optimized for workstation platforms used for graphics applications and engineering CAD drawings. The key features of the X10DAi workstation motherboard are:

  • Dual HSW EP E5-2600 v3 (Socket R3 up to 160W), QPI up to 9.6GT/s
  • Intel C612 chipset
  • 16 DIMM, 1TB Reg. ECC DDR4 up to 2133 MHz
  • Three PCIe 3.0 x16, two PCIe 3.0 x8, one PCIe 2.0 x4 (in x8 slot)
  • Intel dual i210 GbE
  • 10 SATA3, 11 USB Ports (6 USB 3.0)
  • 7.1 HD audio
  • 6x USB 3.0
  • Thunderbolt AOC support
  • 12' x 13' E-ATX Form Factor

This motherboard can handle up to 160W processors, which allows it to run the E5-2699 v3 (16 core) CPUs. Having ten SATA ports is very common on the new platforms, so you should have no issues with storage options.

This board also includes eleven USB ports, and six of those are USB 3.0. This allows a large number of external devices to be connected. We always seem to need more USB ports on our workstations, and the X10DAi is equipped to handle that. 7.1 HD audio and Thunderbolt AOC support are included to round out the features on the X10DAi.

PRICING: You can find the Supermicro X10DAi (Intel C612) Workstation Motherboard for sale below. The prices listed are valid at the time of writing, but can change at any time. Click the link to see the very latest pricing for the best deal.

United States: The Supermicro X10DAi-O (Retail Pack) retails for $403.00 at Amazon, and the Supermicro X10DAi-B (Bulk Pack) retails for $395.00 at Amazon.
